Floodlight EcoMax G2 Low Power

LEDFlood-E2 Re127-19W-3000-WH

Product Code
543006001000
  • Compact aluminium design with clipless cover
  • IP66 protection level against water and dust
  • Compatible brackets and ground spikes available
  • IP65 daylight and motion sensor accessory available

Specifications

Electrical data

Voltage type AC/DC
Max. system power 19 W
Power factor 0.9
Nominal voltage 220|240 V
Max. number of luminaires per miniature circuit breaker B16 (MCB) 110
Max. number of luminaires per miniature circuit breaker C16 (MCB) 130
Surge protection 2.5 kV
Max. inrush current 6.20 A
Inrush time 190.00
Displacement factor (DF) ≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB) 81
Max. number of luminaires per miniature circuit breaker C13 (MCB) 105
Nominal voltage DC 200|300 V

Photometrical data

Colour temperature 3000 K
Rated luminous flux according to IEC 62722-2-1 1900 lm
Luminaire efficacy 100 lm/W
Colour consistency (SDCM) 4.0
Equivalent to Halogen 100W
Colour rendering index (CRI) > 80
CIE Flux Code 51 82 97 99 100

Light technical data

Beam angle 100°

Lifespan

Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000

Capabilities

Dimmability On-Off

Certificates and standards

Degree of protection (IP) IP66
Protection class I
Risk group (EN 62471) RG1
Impact strength IK07
Glow wire test 850°C
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 0.5%
230V Cable length 1.0 m
Housing colour White
Optical material Polycarbonate
Cover material Polycarbonate
Coastal proof Yes
Length 117 mm
Width 127 mm
Height/depth 84.4 mm
Application temperature 25°C
Storage environment -30|60°C
Operating temperature -30|50°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694149770170194054239CT10.131 x 0.121 x 0.057 m0.369 KG
