Spot Projector

LEDSpotProjector-E Rd127-15W-830-36D

Product Code
  • Stylish outdoor spot
  • Sleek award-winning design
  • Suitable for illuminating walls and signages or highlighting objects in parks and gardens
  • IP66 water resistance level and IK07 impact protection
  • Adjustable tilting angle of 180°
  • Die casted aluminium body
  • 1.5 meter cable for convenient connection
  • Earth spike accessory available


Electrical data

Max. system power 15 W
Voltage type AC
Nominal voltage 220|240 V
Frequency 50/60 Hz
Power factor 0.5
Displacement factor (DF) ≥ 0.9
Surge protection 2.5 kV
Max. inrush current 15 A
Inrush time 550 µs
Max. number of luminaires per miniature circuit breaker B16 (MCB) 9
Max. number of luminaires per miniature circuit breaker C16 (MCB) 24
Max. number of luminaires per miniature circuit breaker C13 19
Max. number of luminaires per miniature circuit breaker C10 15

Photometrical data

Equivalent to Halogen 75W
Rated luminous flux according to IEC 62722-2-1 1200 lm
Luminaire efficacy 80 lm/W
Colour rendering index (CRI) ≥ 80
Colour consistency (SDCM) 4

Light technical data

Beam angle 36°


Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000


Dimmability On-Off

Certificates and standards

Degree of protection (IP) IP66
Impact strength IK07
Protection class I
Glow wire test 850°C
Risk group (EN 62471) RG1
With control gear Yes
Type of control gear LED operating device current-controlled
Driver failure rate (at 5,000 hrs) <1%
Input current 0.09 A
230V Cable length 1.5 m
Housing material Aluminium
Housing colour Black
Optical material Polycarbonate
Cover material PC + Glass
Lens material Polycarbonate
Reflector Matt
Finishing Black
Maximum tilt angle 180°
Length 127 mm
Width 127 mm
Height/depth 128 mm
Outer diameter 127 mm
Weight 0.947 kg
Application temperature 25°C
Operating temperature -30|50°C
Storage environment -30|60°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694149775307694054239Carton1163 x 163 x 155 mm1.302 kg


Product Code
Ground spike
Product Code
Coupler/connector straight
