Spot Projector

LEDSpotProjector-E Rd82-8W-830-36D

Product Code
709000027000
  • Stylish outdoor spot
  • Sleek award-winning design
  • Suitable for illuminating walls and signages or highlighting objects in parks and gardens
  • IP66 water resistance level and IK07 impact protection
  • Adjustable tilting angle of 180°
  • Die casted aluminium body
  • 1.5 meter cable for convenient connection
  • Earth spike accessory available

Specifications

Electrical data

Max. system power 8 W
Voltage type AC
Nominal voltage 220|240 V
Frequency 50/60 Hz
Power factor 0.5
Displacement factor (DF) ≥ 0.9
Surge protection 2.5 kV
Max. inrush current 7 A
Inrush time 650 µs
Max. number of luminaires per miniature circuit breaker B16 (MCB) 18
Max. number of luminaires per miniature circuit breaker C16 (MCB) 45
Max. number of luminaires per miniature circuit breaker C13 36
Max. number of luminaires per miniature circuit breaker C10 28

Photometrical data

Equivalent to Halogen 50W
Rated luminous flux according to IEC 62722-2-1 600 lm
Luminaire efficacy 75 lm/W
Colour rendering index (CRI) ≥ 80
Colour consistency (SDCM) 4

Light technical data

Beam angle 36°

Lifespan

Lifetime (L70) 50000 h
Lifetime (L80) 30000 h
On-/Off-cycles 100000

Capabilities

Dimmability On-Off

Certificates and standards

Degree of protection (IP) IP66
Impact strength IK07
Protection class I
Glow wire test 850°C
Risk group (EN 62471) RG1
With control gear Yes
Type of control gear LED operating device current-controlled
Driver failure rate (at 5,000 hrs) <1%
Input current 0.07 A
230V Cable length 1.5 m
Housing material Aluminium
Housing colour Black
Optical material Polycarbonate
Cover material PC + Glass
Lens material Polycarbonate
Reflector Matt
Finishing Black
Maximum tilt angle 180°
Length 83 mm
Width 83 mm
Height/depth 135 mm
Outer diameter 83 mm
Weight 0.718 kg
Application temperature 25°C
Operating temperature -30|50°C
Storage environment -30|60°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694149775311394054239Carton1118 x 118 x 165 mm0.859 kg

Accessoires

Product Code
709098000200
Ground spike
Product Code
543098021900
Coupler/connector straight
