Slim Panel Performer UGR19 G6

LEDPanelS-P6 Sq595-34W-BLE2-TW-U19

Product Code
542003108200
  • High quality LED Slim Panel, suitable for offices (UGR19)
  • Standard IP54 (front side)
  • Recessed, suspended and surface mounting possible

Specifications

Electrical data

Voltage type AC/DC
Nominal voltage 220|240 V
Max. number of luminaires per miniature circuit breaker B16 (MCB) 21
Max. system power 34 W
Max. number of luminaires per miniature circuit breaker C16 (MCB) 35
Power factor 0.9
Max. inrush current 45.00 A
Inrush time 143.0
Displacement factor (DF) ≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB) 13
Max. number of luminaires per miniature circuit breaker C13 (MCB) 17
Nominal voltage DC 180|280 V
Frequency 50|60 Hz

Photometrical data

Equivalent to TL 4x18W
Colour consistency (SDCM) 3
Colour rendering index (CRI) > 80
Colour temperature 2700|6500 K
Luminaire efficacy 140 lm/W
Rated luminous flux according to IEC 62722-2-1 4760 lm
CIE Flux Code 61 88 97 100 100

Light technical data

UGR 19
Beam angle 90°
Beam angle 90°

Lifespan

Lifetime (L70) 100000 h
Lifetime (L80) 70000 h
On-/Off-cycles 100000
Lifetime (L90) 50000 h

Capabilities

Dimmability BLE2

Certificates and standards

Degree of protection (IP) IP54
Protection class II
Impact strength IK03
IP recessed part IP20
Glow wire test 650°C
Risk group (EN 62471) RG0
With control gear Yes
Type of control gear LED operating device current-controlled
Driver failure rate (at 5,000 hrs) 1%
230V Cable length 1 m
Wirethrough No
Housing colour White
Finishing White RAL9003
Optical material PMMA
Cover material Polycarbonate
Length 595 mm
Width 595 mm
Height/depth 25 mm
Application temperature 25°C
Storage environment -20|50°C
Operating temperature -10|45°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
0694149777425594051190CT10.631 x 0.673 x 0.04 m2.6 KG

Accessoires



Accessory Panels - Surface module 600mm x 600mm - White

Product Code
140055484
Surface mounted housing


Accessory Safety cable ceiling kit - 500mm - Stainless steel

Product Code
140060852


Accessory Slim Panel Basic G2 - Mounting springs

Product Code
542003021800
Mounting kit


Accessory Panels - Emergency kit 1 Hour

Product Code
542098000800


Accessory Panels - Emergency kit 3 hours

Product Code
542098000900


Accessory Panels - Frame 644mm x 644mm - White

Product Code
542098009600
Installation frame


Accessory Panels - Surface kit 610mm x 610mm - White

Product Code
542098017600
Surface mounted housing


Accessory Indoor - Junction box - White

Product Code
542098030700
Coupler/connector straight


Accessory Slim Panel Perf. UGR19 G6 - Suspension kit

Product Code
542098045500
Suspension cable


Accessory Smart Lighting - Sensor surface module - White

Product Code
560098000600
Surface mounted housing


Accessory Smart Lighting - Sensor recessed - Microwave (MW)

Product Code
821006001800


Accessory Smart Lighting - Sensor recessed - Passive Infrared (PIR)

Product Code
821006002000


Accessory Smart Lighting - Switch

Product Code
821009000200


Accessory Smart Lighting - Connect box

Product Code
821011002600


Accessory Smart Lighting - Multi switch module

Product Code
821017003400


Accessory Smart Lighting - Relay - 1000 Watt

Product Code
821017003800
